A complete range of low ground pressure tyres suited for agricultural machines in heavy and severe applications.
The unique bias-belt design, maximizes the ground contact area, improving flotation and traction.
The rounded shoulder ensures minimum soil compaction.
Technical Data
| Tyre Description | Section Width | Overall Diameter | Rolling Circumference | Static Loaded Radius | Speed Radius Index | Rim | Permitted Rims | Nominal Pressure | Tread Type | Type | Tube | LOAD CAPACITY PER TYRE |
| 320/60-12 132 (A8) | 320 | 689 | 2049 | 298 | 330 | 10.50I | 4 | Implement | TUBELESS | |||
| 320/60-12 132 (A8) | 320 | 689 | 2049 | 298 | 330 | 10.50I | 4 | Implement | TUBELESS | |||
| 320/60-12 132 (A8) | 320 | 689 | 2049 | 298 | 330 | 10.50I-12 | 4 | Implement | TUBETYPE | |||
| 320/55-15 133 (A8) | 320 | 735 | 2200 | 0 | 345 | 10LB-15 | 9.00-15 | 4 | Implement | TUBELESS | ||
| 280/60-15.5 115 (A8) | 280 | 730 | 2142 | 325 | 350 | AG8.00" | 2.4 | 0 | TUBELESS | |||
| 280/60-15.5 125 (A8) | 280 | 736 | 2194 | 331 | 350 | AG8.00" | 3.6 | 0 | TUBELESS | |||
| 420/55-17 133 (A8) | 420 | 898 | 2667 | 397 | 425 | 13.00-17 | 2 | 0 | TUBELESS | |||
| 500/60-22.5 155 (A8) | 500 | 1170 | 3490 | 525 | 550 | AG16.00x22.5 | 2.4 | 0 | TUBELESS | |||
| 360/60-24 122 (A8) | 360 | 1065 | 3200 | 500 | 495 | W11 | 240 | 0 | TUBELESS | |||
| 500/60-26.5 159 (A8) | 500 | 1260 | 3790 | 560 | 600 | AG16.00x26.5 | 240 | 0 | TUBELESS | |||
| 600/55-26.5 166 (A8) | 600 | 1350 | 3970 | 595 | 625 | AG20.00x26.5 | 2.4 | 0 | TUBELESS | |||
| 620/55B26.5 166 (D) | 620 | 1360 | 4100 | 620 | 635 | AG20.00" | 4 | 0 | TUBELESS | |||
| 600/60-30.5 171 (A8) | 600 | 1500 | 4420 | 655 | 700 | AG20.00 | 240 | 0 | TUBELESS |
