EMR Series
Superior performance for the toughest jobs
The new EMR1031, specially designed for wheel loaders, graders and articulated dump truck applications,is the optimal earthmover radial tire to take on every kind of loading operation.
Extremely versatile, it is made for the toughest work environments: infrastructure and buildingconstruction, landscaping, open pits and quarries.
The right void ratio balance of its tread patterndelivers superior control and a tight grip when needed most, whether working on sandy, rocky or hardsurfaces.
Downloads
From instructions and advice to tips and sizing details , these PDFs cover all the information you will need on the EMR Series.
Sidewall protector
The premium sidewall protector prevents tire damage when working over rough ground, like rocky areas.
Cut-resistant compound
This high performing compound is up to 20% more resistant to cuts and wear compared to standard compounds.
The tire lasts longer, reducing machine downtime, lowering cost per hour.
The tire lasts longer, reducing machine downtime, lowering cost per hour.
Wide tread contact area
The wide footprint area results in even wear, excellent stability and reduced vibration for operator comfort.
High tread depth +10% vs premium competitor
The deeper tread provides longer tire life and boosts the efficiency of your machine. The casing can also be retreaded, maximizing your investment in a sustainable way.
Technical Data
Loader/Grader Service
| Tire size | Tread Pattern TRA | Rim Size (Permitted) | Tread Depth (mm) | Service Description LI/SS Loader/Transport | Tire Load Capacity (kg) at 10 (km/h) | Tire Pressure (bar) | Tire Load Capacity (kg) at 40 (km/h) | Tire Pressure (bar) |
| 17.5 R 25 | L3/G3 | 14.00/1.5-25 (14.00/1.5x25 DC, 14.00/1.3x25 DC) |
31 |
* 176 A2/153 A8 |
7.100 | 4,50 | 3.650 | 3,00 |
| 20.5 R 25 | L3/G3 | 17.00/2.0-25 (17.00/1.7-25) |
36 |
**/* 193 A2/161 A8 |
11.500 | 5,75 | 4.625 | 3,00 |
| 23.5 R 25 | L3/G3 | 19.50/2.5-25 |
37 |
**/* 201 A2/170 A8 |
14.500 | 5,75 | 6.000 | 3,00 |
Product Videos
Want to learn more about the features of the EMR Series? These product videos cover all the key details.
Trelleborg EMR1031
Trelleborg EMR Series
