XP700
Protruding rim protector in order to minimize damage to the wheels
The new Trelleborg XP700 tire has been designed to perfectly match the needs of low intensity material handling operations.
Providing adequate load capacity and good steering ability, it offers the proper reliability, whilst maintaining cost control.
Find your Dealer
Downloads
From instructions and advice to tips and sizing details , these PDFs cover all the information you will need on the XP700.
Technical Data
| Load capacity [kg] | |||||||||
| Size | Alternative Size | Rim | Pattern | LOC + STD | Product Dimensions [mm] | Static | Counterbalanced lift trucks up to 25 km/h | ||
| Overall Diameter | Section Width | Load Wheel | Steering Wheel | ||||||
| 15x4½-8 | 125/75-8 | 3.00D-8 | Traction | ● | 374 | 109 | 1.210 | 1.040 | 800 |
| 5.00-8 | 3.00D-8 | Traction | ● | 451 | 115 | 1.650 | 1.415 | 1.090 | |
| 16x6-8 | 150/75-8 | 4.33R-8 | Traction | ● | 409 | 143 | 1.740 | 1.495 | 1.150 |
| 18x7-8 | 180/70-8 | 4.33R-8 | Traction | ● | 447 | 147 | 2.490 | 2.145 | 1.650 |
| 140/55-9 | 15x5.5-9 | 4,00E-09 | Traction | ● | 373 | 130 | 1.360 | 1.170 | 900 |
| 6.00-9 | 4,00E-09 | Traction | ● | 521 | 128 | 2.190 | 1.885 | 1.450 | |
| 21x8-9 | 200/75-9 | 6,00E-09 | Traction | ● | 514 | 180 | 3.200 | 2.755 | 2.120 |
| 6.50-10 | 5.00F-10 | Traction | ● | 569 | 154 | 2.720 | 2.340 | 1.800 | |
| 200/50-10 | 6.50F-10 | Traction | ● | 451 | 187 | 2.870 | 2.470 | 1.900 | |
| 23x9-10 | 225/75-10 | 6.50F-10 | Traction | ● | 574 | 188 | 4.000 | 3.445 | 2.650 |
| 7.00-12 | 5.00S-12 | Traction | ● | 648 | 163 | 3.380 | 2.920 | 2.240 | |
| 23x10-12 | 250/60-12 | 8.00G-12 | Traction | ● | 576 | 231 | 4.380 | 3.770 | 2.900 |
| 27x10-12 | 250/75-12 | 8.00G-12 | Traction | ● | 670 | 227 | 4.530 | 3.900 | 3.000 |
| 7.00-15* | 29x8-15 | 5.5-15 | Traction | ● | 717 | 177 | 4.115 | 3.545 | 2.725 |
| 8.25-15 | 6.5-15 | Traction | ● | 806 | 194 | 5.510 | 4.750 | 3.650 | |
| 28x9-15 | 225/75-15 (8.15-15) | 7.0-15 | Traction | ● | 683 | 203 | 4.530 | 3.900 | 3.000 |
| 250-15 | 250/70-15 | 7.0-15 | Traction | ● | 710 | 206 | 5.510 | 4.745 | 3.650 |
| 250-15 | 250/70-15 | 7.5-15 | Traction | ● | 710 | 235 | 5.510 | 4.745 | 3.650 |
| 300-15 | 315/70-15 | 8.0-15 | Traction | ● | 808 | 244 | 6.795 | 5.850 | 4.500 |
| 355/65-15 | 32x12½-15 (350-15) | 9.75-15 | Traction | ● | 813 | 269 | 9.060 | 7.800 | 6.000 |
