XP800
The next generation tire, designed for reliability and a solid performance.
The most complex challenge of material handling operations is to reach the highest performance maintaining, at the same time, the cost control.
Trelleborg XP800 has been designed to win this challenge, offering the most resilient tire for medium intensity applications.
It provides great reliability, achieving effective results in everyday conditions.
Available Tires Sizes:
3.00-4** | 4.00-8** | 125/75-8 | 150/75-8 | 180/70-8 | 15x5.5-9 | 200/75-9 | 225/75-10 | 250/60-12 | 250/75-12 | 29x8-15 | 225/75-15 | 250/70-15 | 315/70-15 | 28x12.5-15 | 32x12.5-15 | 290/95-20 | 330/95-20
Please visit the table below for more details.
Downloads
Technical Data
| Load capacity [Kg] | |||||||||
| Tire type & Compound availability STD LOC Both |
Product dimensions [mm] |
Other | Counterbalanced Lift trauck up to 25 Km/h |
||||||
| Size | Alternative Size | Rim | Multi Purpose | Non Marking | Overall Diameter |
Section Width | Static | Load Wheel | Steering Wheel |
| 3.00-4** | 2.10-4 | STD | STD | 252 | 83 | 295 | 260 | 195 | |
| 3.00-4** | 2.50C-4 | STD | STD | 252 | 83 | 295 | 260 | 195 | |
| 4.00-8** | 3.00D-8 | Both | Both | 405 | 110 | 1100 | 950 | 730 | |
| 5.00-8 | 3.00D-8 | Both | Both | 453 | 122 | 1650 | 1415 | 1090 | |
| 15x4 1/2-8 | 125/75-8 | 3.00D-8 | Both | Both | 375 | 121 | 1210 | 1040 | 800 |
| 16x6-8 | 150/75-8 | 4.33R-8 | Both | Both | 413 | 156 | 1740 | 1495 | 1150 |
| 18x7-8 | 180/70-8 | 4.33R-8 | Both | Both | 450 | 162 | 2490 | 2145 | 1650 |
| 140/55-9 | 15x5.5-9 | 4.00E-9 | Both | Both | 375 | 140 | 1390 | 1170 | 900 |
| 6.00-9 | 4.00E-9 | Both | Both | 523 | 148 | 2190 | 1885 | 1450 | |
| 21x8-9 | 200/75-9 | 4.00E-9 | Both | Both | 518 | 191 | 3200 | 2755 | 2120 |
| 6.50-10 | 5.00F-10 | Both | Both | 570 | 167 | 2720 | 2340 | 1800 | |
| 200/50-10 | 6.50F-10 | Both | Both | 452 | 200 | 2870 | 2470 | 1900 | |
| 23x9-10 | 225/75-10 | 6.50F-10 | Both | Both | 578 |
202 |
4000 | 3445 | 2650 |
| 7.00-12 | 250/60-12 | 5.00S-12 | Both | Both | 653 | 179 | 3380 | 2920 | 2240 |
| 23x10-12 | 250/75-12 | 8.00G-12 | Both | Both | 575 | 242 | 4380 | 3770 | 2900 |
| 27x10-12 | 29x8-15 | 8.00G-12 | Both | Both | 674 | 243 | 4530 | 3900 | 3000 |
| 7.00-15* | 29x8-15 | 5.5-15 | Both | Both | 724 | 196 | 4115 | 3545 | 2725 |
| 7.00-15* | 6.0-15 | STD | STD | 724 | 196 | 4115 | 3545 | 2725 | |
| 7.50-15* | 6.5-15 | Both | Both | 747 | 210 | 4530 | 3900 | 3000 | |
| 8.25-15 | 6.5-15 | Both | Both | 812 | 211 | 5510 | 4750 | 3650 | |
| 28x9-15 | 225/75-15 (8.15-15) |
7.0-15 | Both | Both | 689 | 224 | 4530 | 3900 | 3000 |
| 250-15 | 250/70-15 | 7.0-15 | Both | Both | 709 | 244 | 5510 | 4745 | 3650 |
| 250-15 | 250/70-15 | 7.5-15 | Both | Both | 709 | 244 | 5510 | 4745 | 3650 |
| 300-15 | 315/70-15 | 8.0-15 | Both | Both | 810 | 258 | 6795 | 5850 | 4500 |
| 355/45-15* | 28x12.5-15 | 9.75-15 | Both | Both | 683 | 294 | 6610 | 5690 | 4375 |
| 355/50-15* | 9.75-15 | Both | Both | 712 | 296 | 6610 | 5690 | 4375 | |
| 355/65-15* | 32x12.5-15 (350-15) |
9.75-15 | Both | Both | 817 | 295 | 9060 | 7800 | 6000 |
| 10.00-20** | 290/95-20 | 7.0-20 | STD | STD | 1035 | 263 | 7550 | 6000 | 5000 |
| 10.00-20** | 290/95-20 | 7.5-20 | STD | STD | 1035 | 263 | 7550 | 6000 | 5000 |
| 10.00-20** | 290/95-20 | 8.0-20 | STD | STD | 1035 | 263 | 7550 | 6000 | 5000 |
| 12.00-20** | 330/95-20 | 8.0-20 | STD | STD | 1091 | 284 | 9515 | 7560 | 6300 |
| 12.00-20** | 330/95-20 | 8.5-20 | STD | STD | 1091 | 284 | 9515 | 7560 | 6300 |
XP800. Advanced tread design
XP800. The right intensity
Our mission is to support you in choosing the most suitable tire according to the application intensity.
The XP800 is the perfect choice for medium intensity applications, simply identified by the below summary.
Outstanding stability
Optimum tire life
Available compounds
Multipurpose:
standard black compound designed to give the best balanced overall performances. It offers very good wear and rolling resistance.
